Low Profile Stretch Wrap Machine



Scope of application:	LLDPE resin
Working principle:	extrusion casting method
Membrane structure:	ABA
Distribution ratio:	30% and 70%
Product winding maximum width:	500mmX2
Product winding maximum diameter:	300mm
Maximum extrusion volume:	120kg/h
Mechanical maximum linear speed:	120m/min
Maximum extrusion thickness:	0.05mm
Minimum extrusion thickness:	0.006mm
Mechanical voltage:	3-phase 4-wire, 380V, 50HZ
Total installed capacity:	68KW
Mechanical size:	12mX3mX2.5m (LXWXH)
Mechanical weight:	6000KG



Introduction

The Low Profile Stretch Wrap Machine is an advanced packaging equipment that can automatically package products without manual intervention. This kind of machine usually uses linear low-density polyethylene resin to achieve packaging. This film can perfectly wrap the product inside and prevent the product from being damaged during transportation and storage. Secondly, the maximum rolling diameter of this product is 300 mm, and the maximum extrusion thickness is 0.05 mm. Finally, the product weighs 6,000 kilograms, which is characterized by heavy weight.



Feature

Low profile design
The Low Profile Stretch Wrap Machine have a low base height, typically only a few inches high, so no additional platforms or scaffolding are required for placement and operation. This design makes the machine ideal for use in small spaces, such as in tight areas of warehouses or factory equipment.



Save labor
Due to the high degree of automation, we are able to significantly shorten the packaging cycle and reduce the labor required.



Energy efficient
The machine uses an advanced servo motor system that can accurately control the speed and tension of the stretch film, thereby achieving efficient and energy-saving packaging effects.



Customizable
According to the needs of customers, our products can provide various optional configurations such as high-quality sealed packaging, full-width packaging, manual packaging and stretch film wrapping machine packaging to adapt to different packaging needs.



Easy to maintain
The equipment adopts an intelligent design, has a low failure rate, and is easy to maintain and operate. At the same time, users can also perform maintenance and management more conveniently through the remote monitoring system.



















1. Sealed packaging

2. Full width packaging

3. Hand packing

4. Stretch film wrapping machine packaging

5. Horizontal mechanical packaging

6. Packaging of paper tube

7. Packaging of small items

8. Packaging of pipes and cables

9. Stretch form of pallet mechanism packaging



















Q: Why is the model name of your machine the same as the machine from another company?

A: Since these machines have a long history and are very popular in the market, it may be indeed possible that some machine models are similar to others. What we may think is that the machine model does not make a big difference. And the criteria for machines may depend on the technical support and quality of the machines.

Q: Why your price is higher than many suppliers in China?

A: Zhetuo is an old and famous brand of packing machines and we offer machines of high quality and consummate service from inquiry to after-sale.
