High Speed Paper Bag Making Machine
video

High Speed Paper Bag Making Machine

Scope of application:Aluminized film and EPE composite roll
Mechanical speed:150 beats per minute
The maximum width of the pearl cotton raw material unwinding:2000mm
Maximum diameter of pearl cotton raw material unwinding:1500mm
Send Inquiry
Product Introduction






Introduction

The High Speed Paper Bag Making Machine have a modern design with built-in fully automatic function, which can produce different types of paper bags quickly and freely. And the mechanical speed is 150 times per minute, which has the characteristics of fast operation. Secondly, the whole machine adopts advanced motion control system as the main control, double servo system to control fixed length and printed electric eye, can produce different specifications of air pearl cotton insulation bags, our maximum width is 2000 mm, the maximum diameter is 1500 mm. Finally, our application range is aluminized film and EPE composite film.



Feature

High speed production
The High Speed Paper Bag Making Machine produce paper bags incredibly quickly. Using this machine is faster and more efficient than making by hand. And the maximum length of our bags is 600mm, and the maximum width of each bag is 1000mm (including bag mouth and tongue).



Automation
Our products automate the entire production process, from web to finished bag production quickly. This automated process not only increases production efficiency, but also reduces the impact of human factors on the product.



Versatility
Our products can be personalized according to the needs of users, enabling them to complete the production of paper bags of different types, sizes and shapes. This versatile design allows for greater flexibility in production.



High quality output
Our products use high-quality raw materials and advanced manufacturing technology to produce high-quality paper bags. These paper bags can meet different sales environments and needs.



Easy to operate
While producing various types of paper bags, the machine also adopts a visual operation method, making it easy to understand and achieve easier operation. Even beginners can get started quickly.





Mechanical performance parameters



Scope of application: Aluminized film and EPE composite roll
Mechanical speed: 150 beats per minute
The maximum width of the pearl cotton raw material unwinding: 2000mm
Maximum diameter of pearl cotton raw material unwinding: 1500mm
One out of one bag maximum width: 1000mm (including the bag mouth and tongue)
The maximum width of one out of one bag: 500mm (including the bag mouth and tongue)
Maximum length of bag making: 600mm
Machine voltage: 3-phase 4-wire, 380V, 50HZ, 16 square wires
Total machine power: 30KW
Machine size: 18000mmX1500mmX2300mm (LXWXH)
Mechanical weight: 7500KG



Our mode of transportation






FAQ:



1. Are you a trading company or a factory?
We are manufacturers.


2. When can we schedule the shipment?
Typically, we schedule the shipment within 15 days after receiving the deposit. However, for customized machines, the lead time can extend to more than 25 days.


3. Do you offer equipment operation training after the sale?
Certainly. We have the capability to send professional engineers to the work site for equipment installation, adjustment, and operation training. It is worth noting that our engineers possess valid passports.


4. Can you tailor the machine to meet my specific requirements?
Absolutely. We boast a team of experienced engineers and technicians who are equipped to provide personalized services and accommodate your specific requests.
